Dobbelt intelligente funktioner til køretøjer med anhængertræk, reservehjul eller andet fremspring.
Enheden er designet til 24V.
The length of the wires to the sensors is 2.3 m.
System Description:
sensors with fixed assembly to the bumper
fast obstacle detection
excellent coverage of the entire area behind or before the vehicle
when is the obstacle at a distance of 30 cm from the vehicle, you will hear a continuous tone
auto detection (automatic identification of the defective sensor)
excellent coverage of the entire area behind the vehicle, horizontal scan angle of 110° ± 15°
angle washers 0°, 4°, 10° included in the package
sensors core diameter 14 mm
mounting hole 18,8 mm
sensors supplied with 10 cm lenght cable and waterproof connector that ensures easy replacement if necessary
adjustable sensitivity of the sensors on the control unit (2 levels)
the unique learning function (ignoring permanent obstacle - tow bar, spare wheel, frame, ...)
with additional ACC wire (pink wire) for stable power supply(optional connection)
djustable volume directly on the buzzer body (3 levels)
control unit is not waterproof, must be installed in dry place
Technical parameters:
Operating voltage: 9 ~ 27V DC
Working current : < 250Ma
Speaker: 80 ± 10dB
Detection range rear: 0.3 ~ 2.59 m
Detection range front : 0,3 ~ 0,99 m
Operating temperature
ECU: -40°C ~ +80°C
Display: -20°C ~ +70°C
Sensor: -40°C ~ +80°C
Bemærk, dette er en skaffe vare med forlænget leveringstid og der ydes ikke returret på bestillingsvarer/skaffevarer, dvs varer som ikke er lagervarer og som hjemtages specifikt til en ordre.
Derfor venligst sikre dig at det er den rigtige vare til din bil.
